S&M Widemouth Fork 26mm

S&M Widemouth Fork 26mm
The S&M Widemouth Fork 26mm is black
The tried and true S&M Widemouth fork offers plenty of tire clearance in a steeper 26mm offset for a more responsive front end. Less fork offset creates a shorter overall wheelbase for more responsive handling of your entire bike. Nose wheelies, pivots and a balance point thats easier to reach. Believe and achieve. For 20 or 22 wheel sizes.

LEGS
Double Butted, Tapered, 4130 CrMo

DROPOUTS
Laser Cut 3/8 Slot

STEERER TUBE
Integrated Bearing Race. 1 Piece CNC-Machined 4130 CrMo, Extruded 6061 Steerer Tube Insert

STEERER TUBE LENGTH
173mm

COMPRESSION
M24 X 1.5 Thread 6mm Allen Slot

AXLE TO CROWN HEIGHT
20 320mm22 345.9mm

OFFSET
26mm

WEIGHT
1.99 lb (.90 kg) 202.35 lb (1.06 kg) 22

HEAT TREAT
4Q Baked Post-Weld

TIRE CLEARANCE
MAX CLEARANCE 2.45
